OutBack FLEXware DC Disconnect System Enclosure

REAL PEOPLE - NOT "BUY IT" BUTTONS - 888-826-0939

OutBack Power Systems has developed FLEXware-DC a new solution for all of the DC components of a renewable energy power conversion system. The FW500-DC or FW1000-DC saves time, money and space by combining the disconnects, overcurrent protection devices, grounding and control components into an easy to install, single enclosure. The FW500-DC or FW1000-DC are easily modified and expanded as your system grows or changes. Available in the one to two inverter size as the FW500-DC or the one to four Inverter size as the FW1000-DC.

 FLEXware DC Enclosures. See pricing below.

FW500-DC The DC Breaker Enclosure fits at the DC side of one or two FX series inverter/chargers.

It includes a ground bus bar, 500 Amp DC Shunt assembly with negative TBB mounting screws. The enclosure holds up to eight 1 to 80 amp breakers, three 100 or 125 amp and two 175 amp or 250 amp breakers (Not Included)

If you need more room in the enclosure than the FW500DC gives you for two inverter systems, or you want the benefit of extra cooling space for two inverter systems, order the FW1000 enclosures and Mounting Plate and mount your inverters in either the one and three positions or the two and four positions. There's not a big difference in price between the FW500 or the FW1000 system enclosures and your inverters will run cooler.

Requires optional DCA's for connection of each FX series Inverter. See Pricing Below

FW1000-DC The DC Breaker Enclosure fits at the DC side of one, two, three or four FX series inverter/chargers.

It includes a ground bus bar, 1000 Amp DC Shunt assembly with negative TBB mounting screws. The enclosure holds up to eleven 1 to 80 amp breakers, nine 100 or 125 amp and six 175 amp or 250 amp breakers (Not Included)

If you need more room in the enclosure than the FW500DC gives you for two inverter systems, or you want the benefit of extra cooling space for two inverter systems, order the FW1000 enclosures and Mounting Plate and mount your inverters in either the one and three positions or the two and four positions. There's not a big difference in price between the FW500 or the FW1000 system enclosures and your inverters will run cooler.

Requires optional DCA's for connection of each FX series Inverter. See Pricing Below

Shown above are Pam, Patty (Our sales Manager) and Carol (the SEI Instructor) installing components into a DC Enclosure during the last year's Solar Energy International Women's PV design and Installation Course held at Paonia Colorado.

FLEXware Optional Components

1,5,10,15,30,40,50,60,80,100,125,175 & 250 amp DC rated breakers for DC inputs/loads and power inverters

OBP-10100 - OBDC-GFP/2 - Dual 60 amp PV ground fault protection system for two PV charge controller. Multiple DC-GFP/2 can be used on the same system

OBP-09001 Terminal Bus Bar Kits w/ Black, Red , Blue White and BROWN  Insulators available (Ask Us)

OBP-09000 - Ground bus bar kit

OBP-09005 - FLEXware Breaker Bus - Allows connections of two 175 Amp or 250 Amp Breakers. Three 125 amp, Four 80 Amp or three 500 Amp DC Current Shunts.

OBP-09008 - FLEXware Shunt Bus - allows up to four high current cable connections on the same side of the DC Shunt - Includes two 3/8" bolts and mounting screws Solid Brass rated for 1000 Amps.

DC Component Pricing - Low price Guarantee
